性能特點

1.本機適應于生產PE、PP、OPP、PVC等材料邊封袋

2.采用日本伺服馬達控制，主電機采用臺灣變頻調速，意大利光電眼跟蹤彩印，出袋輸送裝置采用進口皮帶及臺灣變頻調速。

3.切刀采用優質合金鋼.高溫加熱不易變形。封輥采用耐高溫硅膠材料。

4.放料架配置E.P.C自動糾偏、磁粉制動張力控制。

5.配套功能：1）圓形透氣孔2）雙面膠裝置3）PE筒膜破邊裝置

1.This machine specialize to make PE、PP、OPP、PVC etc.side sealing bag.

2. Use servo motor feeding control, Main motor use Taiwan invertor control.

Conveying device use high quality conveyer belt&Taiwan invertor control

3.Heat sealing knife use High quality alloy steel.Heated to high temperatures

not easy deaformation.Sealing bar use thermostability silica gel material

4.It has E.P.C automatic control for unwinding.

5. Supporting function:1) Circular holes 2)Adhesive tape device 3)PE tube film Broken edge device.

規格

Specification

型號Model

RQD-400

RQD-600

RQD-700

RQD-800

RQD-1000

制袋寬度Max.Bag Width

400mm

600mm

700mm

800mm

1000mm

制袋長度Max Bag Length

30-600mm

55-600mm

55-700mm

60-700mm

65-800mm

制袋速度Machine speed

30-180pcs/min

30-140pcs/min

30-140pcs/min

30-130pcs/min

30-130pcs/min

制袋厚度thickness of film

0.02-0.20mm

0.02-0.20mm

0.02-0.20mm

0.02-0.20mm

0.02-0.20mm

制袋誤差Tolerance

±1mm

±1mm

±1mm

±1mm

±1mm

整機功率Power Required

3.0KW

3.2KW

3.4KW

3.6KW

3.8KW

設備尺寸Machine size

3100*1000*1420mm

3100*1250*1420mm

3100*1350*1420mm

3100*1450*1420mm

3100*1650*1420mm

機器重量Machine N.W

750kg

950kg

1050kg

1150kg

1250kg
